CDU-531

SONY CORPORATION

CDU-531

Device Type

Internal CD-ROM

Interface

Sony

Spin Rate

1x

Formats Supported

Audio CDs, Audio combined CD-ROM disks, CD-ROM (Mode 1 & 2),

Red & Yellow Book Audio

View

Top

CONNECTIONS

Function

Label

Audio line out

CN1

USER CONFIGURABLE SETTINGS

Setting

Label

Position

Termination enabled

JP1/1

Closed



Termination disabled

JP1/1

Open



DRQ select

JP1/2

Closed



Wait select

JP1/2

Open

Note: Only change the setting of JP1/2 (DRQ to Wait) if instructed in your manual.

DRIVE SELECT ID

Drive ID

JP1/3

JP1/4

JP1/5

JP1/6

0

Open

Open

Open

Closed



1

Open

Open

Closed

Open



2

Open

Closed

Open

Open



3

Closed

Open

Open

Open
